CLION-MARINE CHILLER 50.000 – 270.000 BTU

5_chillers

CLION-MARINE CHILLER 50.000 – 270.000 BTU

Clion-marine chiller a/c system from 50000 to 270000 BTU.

Chillers
– Full inverter Reverse cycle chillers in stainless steel housing.
– No inductive loads at start up, low energy consumption and easy to install
– Integrated automatic fuses with manual reset.
– Eco modus for running on low shore supplies.
– Control box with prewired EMC protected cable loom , which can be installed a maximum of 0,8-1,2 mtr from the chiller.

Chiller package
The Clion-Marine chiller package consists of the following items: chiller, complete prewired EMC protected control box and cable loom
(0,8-1mtr), mounting kit control box (preinstalled at front of the chiller), touch screen display, Vimar black bezel, RJ45 cable 10 mtr.

  • Description
  • Reviews (0)

Description

Multi-functional, energy-efficient air conditioning

Clion Marine Chillers are equipped with compressors driven by continuously-variable Inverters. This technology is characterised not only by extremely low power consumption and quiet operation, but the variable power. Power is automatically adjusted to the cooling capacity required at any given time. This creates a stable interior climate and prevents annoying power surges. The system can also be used for heating when the seawater temperature is 6 0C or more, thanks to the practical reverse cycle function. In addition, the system can be easily integrated with an existing diesel heater.

Simple operation and installation

Clion Marine air conditioning systems are characterised by their high-quality design. The solid stainless steel housings means that the chillers are suitable for extreme conditions, climatic or otherwise. Operation of the chillers is made easy thanks to the touchscreen control panel or remote control.

Chillers
– Full inverter Reverse cycle chillers in stainless steel housing.
– No inductive loads at start up, low energy consumption and easy to install
– Integrated automatic fuses with manual reset.
– Eco modus for running on low shore supplies.
– Control box with prewired EMC protected cable loom , which can be installed a maximum of 0,8-1,2 mtr from the chiller.

Chiller package
The Clion-Marine chiller package consists of the following items: chiller, complete prewired EMC protected control box and cable loom
(0,8-1mtr), mounting kit control box (preinstalled at front of the chiller), touch screen display, Vimar black bezel, RJ45 cable 10 mtr.

Chillers are including control box and display
* Dimensions of the chillers are without control box
**Chilled waterflow depends on amount of airhandlers
***Mounting brackets need to be ordered seperately
